Stain Unit
A. Stain Unit Cover – Open this cover to inspect the interior of the stain unit. Access can be gained
for cleaning or maintenance tasks. Locked during operation.
B. Stain Unit – Depending upon protocol; fixes, stains, rinses and dries the prepared slides.
There are 7 staining pools which are filled up with the following reagents. The types of reagent varies
depending on the staining method. Samples move through the staining pool in the direction of the arrow
as illustrated above.
