Sampler/Manual
Touch to register sample information and slide preparation conditions.
Select to display the [Manual Preparation] dialog box or [Sampler Preparation] dialog box.
The icon displayed varies depending on the selected slide preparation method and settings.
Error Message
Displays the highest priority error among all current errors. DI-60 & CF-70 (if connected) errors are
also displayed here.
Mode
Touch to select the slide preparation mode.
Display
Slide Preparation
Setting
Sampler Preparation
N/A
Manual Preparation
[Cap Open] is OFF
[Cap Open] ON
[RBT] is ON
Colour
Status
Orange background/black text
Caution
Red background/white text
Warning
