Analyser components – SP-50 Overview
Sysmex House, Garamonde Drive, Wymbush, Milton Keynes, MK8 8DF, United Kingdom · Phone +44 333 320 3460 · Fax +44 1908 267 901
academy.training@sysmex.co.uk· www.sysmex.co.uk
7
8. Start Switch – Press to start manual analysis.
9. Status Indicator LED - Shows the current status of the analyser.
LED Indicator Light
Description
Green
Ready (Analysis or maintenance is possible)
Flashing Green
Starting up / Analysis in progress / Maintenance in progress
Orange
Sample analysis stopped / not possible. An error has occurred, but the
instrument is still operational.
Flashing Orange
Starting up/Preparing a slide/Switching the slide preparation mode/ Shutting
down/Sleeping
Red
Stopped - Error (without alarm) / initialising system / Analyser ready to be
turned off at the end of shutdown
Flashing Red
Stopped - Error(with alarm)
Not Lit
Powered OFF
10. Manual Magazine Holders - This is used for loading manual slides into the analyser for manual
staining.
11. Lower Front Cover - Open this cover to inspect the interior of the main unit to perform cleaning
or maintenance tasks. Analyser must be turned off.
12. Manual Magazine Holder Status LED – Shows the current status of the manual magazine
holder. A magazine cannot be loaded or removed while the LED is flashing.
LED Indicator Light
Description
Green
Containing magazine
Red
Error
Not Lit
Powered OFF
