Diagnostics
6–16 TA I
NSTRUMENTS
DSC A
UTOSAMPLER
CE
The Rear Switches Test
The Rear Switches Test determines the current
settings of the system configuration jumpers
inside the Autosampler CE.
1. Access the Autosampler CE keypad by
loosening the captive thumbscrews on the
keypad cover and tilting the cover down.
2. Press the TEST key four times. The Auto-
sampler CE screen displays:
Test
Rear Switches
3. Press ENTER to select the test displayed on
the screen. The Autosampler CE displays a
series of 0s and 1s. For example:
Rear Switches
10000 01100
A zero (0) digit means that the jumper is off;
one (1) indicates that the jumper is on.
When you have finished using the Autosampler
CE keypad, remember to close the keypad cover
and finger-tighten the thumbscrews before
starting a method.
NOTE:
