Diagnostics
6–18 TA I
NSTRUMENTS
DSC A
UTOSAMPLER
CE
The GPIB Test
The GPIB test enables you to verify the GPIB
address setting for the Autosampler CE (for
further information, see Chapter 2).
1. Access the Autosampler CE keypad by
loosening the captive thumbscrews on the
keypad cover and tilting the cover down.
2. Press the TEST key six times. The Auto-
sampler CE screen displays:
Test
GPIB
3. Press ENTER to select the test displayed on
the screen. The screen should display a
numeral ten higher than the address you set
when you configured your DSC:
GPIB
Address = xx
For example:
DSC 2920 address = 1
Autosampler CE address = 11
4. Press ESCAPE/CLEAR to exit the GPIB
test.
When you have finished using the Autosampler
CE keypad, remember to close the keypad cover
and finger-tighten the thumbscrews before
starting a method.
NOTE:
