Takeuchi TB215R - Removing the Hydraulic Tank; Installing the Hydraulic Tank

DISASSEMBLY AND ASSEMBLY
HYDRAULIC TANK
2
4
HYDRAULIC TANK 4H0AX00
Removing the hydraulic tank
The numbers in parentheses ( ), listed after the names of
parts throughout this document are used to refer to the
same parts as the numbers listed in the construction di-
agram and parts lists.
1. Remove the covers from the perimeter around the
hydraulic tank.
“Removing the covers”
2. Drain the hydraulic oil from the hydraulic tank (1).
a. Slowly loosen the oil plug (6) to release the inter-
nal pressure in the hydraulic tank.
b. Drain out the oil from the drain plug (13).
• Tank level capacity: 16.1 L (4.3 US gal.)
3. Disconnect the low-pressure hoses from the hydrau-
lic tank.
4. Disconnect the high-pressure hoses from the hy-
draulic tank.
• Attach an identification tag on each hoses to avoid
mixing them up during reassembly.
5. Take out the bolts holding the hydraulic tank in place,
and suspend the hydraulic tank and remove it.
Bolt: ThreeBond #1324
Bolt: 47 N·m (34.7 ft.-lb)
Hydraulic tank: 20 kg (43 lb)
Installing the hydraulic tank
For installation of the hydraulic tank, follow the same pro-
cedures as for removal but in the reverse order.
