Takeuchi TB215R - Slew Right or Left Is Not Possible

3
5
SLEWING
TROUBLESHOOTING
5D0AX00SLEWING
Slew right or left is not possible
1 Check the pilot valve
Faulty
Repair or replace the pilot
valve
Normal
2
Check the spool opera-
tion
Faulty

block
Normal

Check the slew relief
valve
Faulty
Repair or replace the slew re-
lief valve
Normal
4 The slew motor is faulty
Repair or replace the slew
motor
1. Check the pilot valve
It is likely that only the pilot valve spool on the side


2. Check the spool operation
It is likely that the spool does not move in the direction

    -
eration”
3. Check the slew relief valve
  

4. The slew motor is faulty
“4. Disassembly and assembly, Slew motor”
'$,=
