Takeuchi TB215R Workshop Manual

SERVICE DATA
SPECIFICATION TABLES
1
2
SPECIFICATION TABLES 2B0AX003
SPECIFICATION TABLES
Performance
*: At the operator location as stipulated by ISO 6396: 2008.
Dimensions of completed machine
Operating mass
215000003 to
215002407
Rubber
crawler
kg (lb) 1575 (3470)
Steel
crawler
kg (lb) 1670 (3680)
from
215002408
Rubber
crawler
kg (lb) 1610 (3550)
Steel
crawler
kg (lb) 1675 (3695)
Rated output
Net (ISO 14396) kW/min
-1
(hp/rpm) 11.5/2400 (15.4/2400)
Net (ISO 9249/SAEJ 1349)
kW/min
-1
(hp/rpm)
11/2400 (14.8/2400)
Bucket capacity
Heaped capacity m
3
(ft
3
) 0.038 (1.34)
Struck capacity m
3
(ft
3
) 0.028 (0.99)
Standard loading mass kg (lb) 70 (150)
Slew speed min
-1
(rpm) 9.2 (9.2)
Travel speed
Rubber
crawler
1st km/h (mph) 2.2 (1.37)
2nd km/h (mph) 4.2 (2.61)
Steel crawler
1st km/h (mph) 2.1 (1.3)
2nd km/h (mph) 4 (2.49)
Maximum tractive force kN (lbf) 19.4 (4360)
Gradeability
%58
deg. 30
Ground pressure
215000003 to
215002407
Rubber
crawler
kPa (psi) 26.2 (3.8)
Steel
crawler
kPa (psi) 28.2 (4.09)
from
215002408
Rubber
crawler
kPa (psi) 26 (3.77)
Steel
crawler
kPa (psi) 27.3 (3.96)
Noise level
Sound-power level dB (A) 93
Sound-pressure level* dB (A) 80
Overall length
215000003 to
215002407
Standard
arm
Rubber
crawler
mm (in.) 3445 (135.6)
Steel
crawler
mm (in.) 3445 (135.6)
from
215002408
Rubber
crawler
mm (in.) 3455 (136)
Steel
crawler
mm (in.) 3445 (135.6)
Overall width
During normal operation mm (in.) 1300 (51.2)
Track retracted mm (in.) 980 (38.6)
Overall height
Rubber crawler mm (in.) 2345 (92.3)
Steel crawler mm (in.) 2350 (92.5)
