Takeuchi TB215R Workshop Manual

SERVICE DATA
DIMENSIONAL DRAWING
4
2
DIMENSIONAL DRAWING 2A0AX001
J
2
: Long blade specifications
K
2
: Long blade specifications
Unit: mm (in.)
Standard arm Long arm
215000003 to
215002407
from 215002408
215000003 to
215002407
from 215002408
Rubber crawler Rubber crawler
A 3815 (150.2) 3815 (150.2) 4000 (157.5) 4000 (157.5)
B 3760 (148.0) 3760 (148.0) 3945 (155.4) 3945 (155.4)
C 2190 (86.2) 2190 (86.2) 2390 (94.1) 2390 (94.1)
D 1780 (70.1) 1780 (70.1) 1970 (77.6) 1970 (77.6)
E 2705 (106.5) 2705 (106.5) 2760 (108.7) 2760 (108.7)
F 3430 (135.1) 3430 (135.1) 3570 (140.6) 3570 (140.6)
G 2400 (94.6) 2400 (94.6) 2545 (100.2) 2545 (100.2)
H 835 (32.9) 835 (32.9) 635 (25) 635 (25)
J 215 (8.4) - 215 (8.4) -
J
2
310 (12.1) 310 (12.1) 310 (12.1) 310 (12.1)
K 210 (8.3) - 210 (8.3) -
K
2
365 (14.3) 365 (14.3) 365 (14.3) 365 (14.3)
