Takeuchi TB215R - Installing the Fuel Tank; Removing the Fuel Tank

DISASSEMBLY AND ASSEMBLY
DRIVE SYSTEM
8
4
DRIVE SYSTEM 4B0AX00
Removing the fuel tank
1. Remove the canopy.
2. Remove the covers from the perimeter around the
tank.
3. Loosen the drain plug (9), and let the fuel drain out.
• Fuel tank capacity: 22 L (5.8 US·gal)
4. Disconnect the fuel hoses from the fuel tank, sedi-
menter, and fuel pump.
5. Take out the bolts holding the fuel tank (1) in place,
and remove the fuel tank (1).
Bolt: 22.6 N·m (16.7 ft-lb)
Installing the fuel tank
For installation, follow the same procedures as for remov-
al but in the reverse order.
