Takeuchi TB215R Workshop Manual

SERVICE DATA
DIMENSIONAL DRAWING
2
2
DIMENSIONAL DRAWING 2A0AX001
H
2
: With the crawler extended
R
2
: Side plate attached
S
2
: Long blade specifications
U
2
: Long blade specifications
X
2
: Long blade specifications
Unit: mm (in.)
Standard arm Long arm
215000003 to
215002407
from 215002408
215000003 to
215002407
from 215002408
Rubber crawler Rubber crawler
A 3445 (135.6) 3455 (136.1) 3440 (135.5) 3450 (135.9)
B 980 (38.5) 980 (38.5) 980 (38.5) 980 (38.5)
C 2345 (92.2) 2345 (92.2) 2345 (92.2) 2345 (92.2)
D 720 (28.3) 720 (28.3) 720 (28.3) 720 (28.3)
E 460 (18.1) 460 (18.1) 460 (18.1) 460 (18.1)
F 1155 (45.6) 1205 (47.4) 1155 (45.6) 1205 (47.4)
G 1520 (59.9) 1570 (61.8) 1520 (59.9) 1570 (61.8)
H 1300 (51.2) 1300 (51.2) 1300 (51.2) 1300 (51.2)
H
2
980 (38.6) 980 (38.6) 980 (38.6) 980 (38.6)
J 230 (9.1) 230 (9.1) 230 (9.1) 230 (9.1)
K 205 (8.0) 205 (8.0) 205 (8.0) 205 (8.0)
L 1450 (57.0) 1450 (57.0) 1470 (57.9) 1470 (57.9)
M 1185 (46.7) 1185 (46.7) 1210 (47.6) 1210 (47.6)
P 395 (15.6) 395 (15.6) 395 (15.6) 395 (15.6)
Q 555 (21.9) 555 (21.9) 555 (21.9) 555 (21.9)
R 980 (38.6) 980 (38.6) 980 (38.6) 980 (38.6)
R
2
1300 (51.2) 1300 (51.2) 1300 (51.2) 1300 (51.2)
S 250 (9.8) - 250 (9.8) -
S
2
310 (12.1) 310 (12.1) 310 (12.1) 310 (12.1)
T 2725 (107.3) 2725 (107.3) 2720 (107.1) 2720 (107.1)
U 855 (33.6) - 855 (33.6) -
U
2
1200 (47.2) 1200 (47.2) 1200 (47.2) 1200 (47.2)
V70707070
W50505050
X 3585 (141.1) - 3580 (140.9) -
X
2
3970 (156.2) 3970 (156.2) 3965 (156.1) 3965 (156.1)
