8
4
CONTROL V
AL
VE
DISASSEMBL
Y AND ASSEMBL
Y
4J0AX00
CONTROL V
AL
VE
Port relief valve
1.
Housing
2.
Plug
3.
Sleeve
4.
Main poppet
5.
Piston
6.
Needle valve
7.
Spring
8.
Spring
9.
Set screw
10.
Washer
11.
Lock nut
12.
O-ring
13.
Backup ring
14,
O-ring
15,
Backup ring
16,
O-ring
17.
O-ring
18.
Spring
19.
O-ring
Anti-cavitation valve
-$)=






1.
Plug
2.
Poppet
3.
Spring
4.
O-ring
5.
Backup ring
6.
O-ring
153
155
