FUNCTION
SELECTOR VALVE
4
3
SELECTOR VALVE 3K8AQ00
2. Turn the lever (3) clockwise 90°.
3. Tighten the wing bolt (1) by hand.
• The end of the wing bolt (1) should go into the
anti-rotation hole in the body (2).
3K8AQ07Z
3
3K8AQ08Z
1
2
