Set/Reset Vertical Tabs in Channels
ESC b
Select Vertical Tab Channel
ESC /
Data Structure
ASCII ESC "b" <m> <n
1
>...<n
16
> NUL set vertical tabs in channels
➊
hex. 1B 62 <m> <n1>...<n16> 00
dec. 27 98 <m> <n1>...<n16> 0
ASCII ESC "b" <m> NUL clear all tab settings
hex. 1B 62 <m> 00
dec. 27 98 <m> 0
ASCII ESC "/" <m> select vertical tab channel
➋
hex. 1B 2F <m>
dec. 27 47 <m>
Description
➊
Up to 16 vertical tabs for one channel <m> can be set. the number of tab channels m
ranges from 0 to 7. The value of n, given in lines, ranges from 1 to 255.
Channel 0 can be set via ESC B. The default value is m=0.
➋
This command is used to select one of the eight vertical tab channels. The value of m
ranges from 0 to 7.
Print Positioning
57
