7265 Programmer’s Manual
50
Copyright © 2004 TallyGenicom Chapter 3 ANSI Bar Codes
EAN-8 (Style 5)
1 Bars per character: 2 dark bars and 2 light bars
2 Character set: 0 through 9
3 Start/Stop characters: 2 dark bars and 1 light bar
4 Center character code: Yes
5 NULL character: Yes
6 Intercharacter gap: None
7 Characters per symbol: 8
8 Check digit: The check digit can be
supplied by the data source.
9 Delimiters: Space, comma, horizontal tab, hp_relative
10 HR characters (without guard bars): Currently selected font, special HR font,
special OCR-A/OCR-B font (120 DPI only), HR characters (with guard bars):
OCR-B font
11 CPI at default element widths: 7.385
EAN-13 (Style 6)
1 Bars per character: 2 dark bars and 2 light bars
2 Character set: 0 through 9
3 Start/Stop characters: 2 dark bars and 1 light bar
4 Center character code: Yes
5 NULL character: Yes
6 Intercharacter gap: None
7 Characters per symbol: 13
8 Check digit: The check digit can be
supplied by the data source.
9 Delimiters: Space, comma, horizontal tab, hp_relative
10 HR characters (without guard bars): Currently selected font, special HR font,
special OCR-A/OCR-B font (120 DPI only), HR characters (with guard bars):
OCR-B font
11 CPI at default element widths: 8.283
