72655 Programmer’s Manual
49
Copyright © 2004 TallyGenicom Chapter 3 ANSI Bar Codes
Matrix 2 of 5 (Style 2)
1 Bars per character: 3 dark bars and 2 light bars
2 Character set: 0 through 9
3 Start/Stop characters: 3 dark bars and 2 light bars
4 Center character code: None
5 NULL character: Yes
6 Intercharacter gap: None
7 Characters per symbol: Variable
8 Check digit: None
9 Delimiters: Space, comma, horizontal tab, hp_relative
10 HR characters: Currently selected font, special HR font, special OCR-A/OCR-B
font (120 DPI only)
11 CPI at default element widths: 6.0
12 Combined start-stop character length: 0.278"
Code 3 of 9 (Style 4)
1 Bars per character: 5 dark bars and 4 light bars
2 Character set: 0 through 9, upper case letters A through Z characters - . $ / + %
and the space character
3 Start/Stop characters: Yes
4 Center character code: None
5 NULL character: Yes
6 Intercharacter gap: None
7 Characters per symbol: Variable
8 Check digit: None
9 Delimiters: Comma, asterisk (use in pairs--one before the bar code symbol and
one following it), horizontal tab, hp_relative
10 HR characters: Currently selected font, special HR font, special OCR-A/OCR-B
font (120 DPI only)
11 CPI at default element widths: 3.78
12 Combined start-stop character length: 0.514"
