7265 Programmer’s Manual
54
Copyright © 2004 TallyGenicom Chapter 3 ANSI Bar Codes
Code 93 (Style 15)
1 Bars per character: 3 dark bars and 3 light bars
2 Character set: All 128 ASCII characters
3 Start/Stop characters: Yes. (Stop character has 4 dark bars and 3 light bars)
4 Center character code: None
5 NULL character: Yes
6 Intercharacter gap: No
7 Characters per symbol: Variable
8 Check digit: Always required. Must be generated by data source. See page 58
9 Delimiters: Horizontal tab. (When no tabs are defined, a space is inserted.),
hp_relative
10 HR characters: Currently selected font, special HR font, special OCR-A/OCR-B
font (120 DPI only)
11 CPI at default element widths: 6.85
12 Combined start-stop character length: 0.333"
Code 128 (Style 16)
1 Bars per character: 3 dark bars and 3 light bars
2 Character set: Any of 3 subsets. The printer automatically shifts among subsets
based on the data that you send. Subset A --All standard alphanumeric
keyboard characters, control characters and special characters Subset B --All
standard alphanumeric keyboard characters, lower case alpha characters and
special characters Subset C --Set of 100 digit pairs from 00 to 99
3 Start/Stop characters: Yes
4 Center character code: None
5 NULL character: Yes
6 Intercharacter gap: None
7 Characters per symbol: Variable
8 Check digit: Automatically generated by the printer. (Cannot be disabled.)
9 Delimiters: Horizontal tab. (When no tabs are defined, a space is inserted.),
hp_relative
10 Automatic data compression and subset selection
11 CPI at default element widths: 11.07
12 Combined start-stop character length: 0.583"
