Definition of NLQ Characters (9 needle printer)
The definition of NLQ characters is more comprehensive than the definition of draft char-
acters, since a larger number of dots is required.
User-defined NLQ characters can only be generated in the NLQ mode of the printer.
Data structure
ASCII ESC "&" NUL <x> <y> <d
0
><d
1
><d
2
><n
1
>...<n
k
> (data 1. character)
<d
0
><d
1
><d
2
><n
1
>...<n
k
> (data 2. character)
hex. 1B 26 00
dez. 27 38 0
Description
x first character to be redefined
y last character to be redefined
d
0
leading space of the character
d
1
number of columns of the defineded character
d
2
following space of the character
k number of data bytes to transmit
n
1
...n
k
data bytes (3 data-bytes for one column)
Values of parameters:
0 ≤ d
0
≤ 20
0 ≤ d
1
≤ 20
0 ≤ d
2
≤ 20
k = 3
∗
d
1
If only a single download character is to be defined, x = y is to be set.
When this command is transferred to the printer, first of all, all data in the print buffer are
output.
