TallyGenicom Matrix Printer - 24 Needle Printer

24 needle printer
Data Structure
ASCII ESC "&" NUL <x> <y> <d
0
><d
1
><d
2
>n
1
...n
3
(data first character)
<d
0
><d
1
><d
2
>n
1
...n
3
(data second character) ...
hex. 1B 26 ...
dec. 27 38 ...
Description
x first character to be redefined
y last character to be redefined
d
0
leading space of the character
d
1
number of columns of the defineded character
d
2
following space of the character
n
1
...n
3
three data bytes for one column in DPQ and LQ, two data bytes for
superscript or subscript characters or 15 cpi character (DPQ + LQ)
If the download character is only being assigned one character code, specify x = y.
Limitations for d
0
, d
1
and d
2
print quality d
0
d
1
d
2
d
0
+d
1
+d
2
DPQ 10 cpi ≥ 0 ≤ 12 ≥ 0 ≤ 12
DPQ 12 cpi ≥ 0 ≤ 10 ≥ 0 ≤ 10
DPQ 15 cpi ≥ 0 ≤ 8 ≥ 0 ≤ 8
LQ 10 cpi ≥ 0 ≤ 36 ≥ 0 ≤ 36
LQ 12 cpi ≥ 0 ≤ 30 ≥ 0 ≤ 30
LQ 15 cpi ≥ 0 ≤ 24 ≥ 0 ≤ 24
LQ proportional ≥ 0 ≤ 42 ≥ 0 ≤ 42
LQ super/subscript ≥ 0 ≤ 37 ≥ 0 ≤ 37
If defined character density (10/12/15 cpi) is selected, d
0
and d
2
will be ignored and the
defined character is centered.
If more columns than d
1
will be defined for one character, it is printed more to the right
and can overlap the next character. The absolute limit for d
1
is 15 columns in DPQ and
42 columns in LQ.
92
Download Character Generator
