7265 Programmer’s Manual
22
Copyright © 2004 TallyGenicom Chapter 2 ANSI
Vertical Movement
Absolute positions are calculated from the top and left print references without respect to margin
settings. The top of a character cell located at vertical position-absolute 0 is at top print reference.
The left edge of a character cell located at horizontal position-absolute 0 is at the left print
reference. If the default left print reference is current, and if the left tractor position(s) are as
shipped, then this is about 0.6 inches from the left edge of the paper.
Top and left print references are adjustable from the printer menu.
CAUTION: Do not attempt reverse paper motion across a perforation, since this may cause the
paper to snag on the print head. Vertical position accuracy is not specified for reverse paper
moves greater than 1.5 inches.
To
Shee
Extreme
Left Position
A
Character Printed at Zero Position
To Next Page
