The vertical resolution is 72 dpi.
The graphics image is printed vertically closed at a line feed of
80
⁄
720
inch. (Also see the
sequences Spacing Increment (SPI), page 15, and Set Line Spacing (SLS), page 26.
Example: CSI 80 ; SP G).
Example for calculation of n
1
and n
2
:
The length of graphics is 80 bytes.
n
2
= number of bytes divided by 256
= int (
80
⁄
256
)
= dec.0
= hex.00
n
1
= remainder of division of n
2
= 80 mod 256
= dec.80
= hex.50
Graphics data and text data can be mixed within one line.
Relationship between graphics data and needles:
Needle Data byte
1/3
•
Bit 7
4/5
•
Bit 6
6/8
•
Bit 5
9/10
•
Bit 4
11/13
•
Bit 3
14/15
•
Bit 2
16/18
•
Bit 1
19/20
•
Bit 0
66 Graphics
