109
unit : millimeters
TR-1106 Fluoropolymer-Coated Sensor
Cable Length: 0.6 m
Thermal-Constant
In the air: Approx. 30 Sec.
In agitated water: Approx. 4 Sec.
TR-1220 Stainless Protection Sensor
Cable Length: 2 m
Thermal-Constant Time
In the air: Approx. 36 Sec.
In agitated water: Approx. 7 Sec.
TR-1320 Stainless Protection Sensor
Cable Length: 2 m
Thermal-Constant Time
In the air: Approx. 12 Sec.
In agitated water: Approx. 2 Sec.
Materials :
Thermistor Stainless Pipe (SUS316) Fluoropolymer-Coated Compaction Tube Fluoropolymer-Coated
Electrical Wire
Possible Measurement Range : - 60 to 155 °C
Sensor Temperature Durability : - 70 to 180 °C
Meaurement Accuracy :
Average+/-0.5 °C (-40 to 80 °C), Average +/-1.0 °C (-60 to -40 °C / 80 to 100 °C), Average +/-2.0 °C (100 to 155 °C)
Sensor Extension Cable (Temp Sensor Only)
unit : millimeters
TR-1C30 Sensor Extension Cable
Cable Length: 3.0 m
Materials:
Vinyl Coated Electrical Wire
NOTE:
- Can not be used with Temperature / Humidity Sensors.
- Only one extension cable can be used with each sensor.
- When using an extension cable there will be a gap of +0.3°C at normal temperature and at -50°C ,
a gap of +0.5°C may occur.
