27
Connecting to a Network
Following are some examples of ways to connect a TR-7W logger to a
network. Please select the connection method that suits your network
environment.
Connecting to a HUB for Intracompany Communication
To ensure a proper connection make sure that the plug is completely inserted.
To HUB
Connection Examples
Connecting Directly to PC for Communication
If communication is not possible with the supplied LAN cable; please purchase a cross
LAN cable separately.
To ensure a proper connection make sure that the plug is completely inserted.
To Computer
Connection Examples
To Next Page
