SAFETY RULES AND OPERATING INSTRUCTIONS
Safety Rules
STANDARD SPECIFICATIONS*
ITEM Model SPECIFICATION
Occupancy SS-534, MX-600 Driver
SS-536, SS-546 Driver + 1-Passenger on fold down seat
NO PASSENGER IF USED FOR TOWING TRAILER
Dimensions SS-534 76.5L x 28.5W x 42 H Inches (1943L x 724W x 1067H mm)
SS-536 86.5L x 30W x 41H Inches (2197L x 762W x 1041H mm)
SS-546 89L x 30W x 41H Inches (2261L x 762W x 1041H mm)
MX-600 86L x 32W x 41H Inches (2174L x 813W x 1041H mm)
Turning Radius SS-534, SS-536 75 inches (1905 Millimeters)
SS-546 81 inches (2057 Millimeters)
MX-600 81 inches (2057 Millimeters)
Maximum Speed 10 mph (16 kph) Do not exceed safe speed for conditions
(Hard level surface, no load)
Dry Weight (Without Battery) SS-536, MX-600 543 pounds (246 kg)
SS-534 481 pounds (218 kg)
SS-546 598 pounds (271 kg)
Battery specifications:
Min/Max Battery Weight All 232 lbs to 320 lbs (105 kg to 145 kg)
Voltage All 24 DC
Deck Dimensions SS-534 23.5 x 27.5 inches (597 x 699 mm)
SS-536, SS-546 19 x 30 inches (483 x 762 mm)
MX-600 27 x 30 inches (686 x 762 mm)
Maximum Carried Load SS-534 500 pounds (227 kg) Note: Load centered on deck
SS-536, SS-546, MX-600 600 pounds (272 kg) Note: Load centered on deck
Electrical System All Curtis PMC , 275 Amp Motor Control
Transmission SS-534 Open Belt drive Reduction to Automotive Hypoid Differential
SS-536, SS-546, MX-600 Oil Bath Helical Gear Reduction to Automotive Type Hypoid Differential.
Motor All 4.5Horse Power (## kW) @ 935 rpm
Brakes SS-534 Rear Drive Line Band Brake, Hand Operated Mechanical Park Brake
SS-536, SS-546, MX-600 Rear Drum, Hand Operated Mechanical Park Brake
Steering Manual
Tires 4.80 x 8 Load Range B Pnuematic
Instrumentation Battery Status Gauge, Key Switch, Horn Switch, Forward/Reverse Switch,
Headlight Switch
This vehicle conforms to requirements for Type E vehicles as described in O.S.H.A. Standard Section 1910.178
(Powered Industrial Trucks) and with all applicable portions of the American National Standard for Operator Controlled
Industrial Tow Tractors (ANSI B56.8).
* - Specifications are subject to change without notice. *** - Not available at time of printing
