Taylor-Dunn MX-026-00 - Frame and Body, Misc Body Trim; Frame and Body, Toolbox, MX-600

Illustrated parts
Parts
Page 25
* Not available at time of printing
Frame and Body, Toolbox, MX-600
1
2
3
4
5
6
Item No. Part No. Description Qty
1 91-340-25 Tool Chest 1
2 00-300-02 Trim 1
3 94-400-32 Double Sided Tape 3 ft
4 88-140-11 1/2"NC X 1" Hex Head Bolt 4
5 88-148-61 1/2" SAE Washer 8
6 88-159-84 1/2"NC Locknut 4
Not Shown 91-340-21 Tool Box Lock 1
91-340-26 Keys for Toolbox Locks 1
00-300-08 Steel Deck Cover 1
Frame and Body, Misc Body Trim
Frame and Body
Item No. Part No. Description Qty
94-035-01 Plastic Cowl Trim sold by the foot
94-201-00 T/D Emblem
98-2554-10 Throttle Pedal
