Taylor-Dunn MX-026-00 - Motor Service Limits and Specifications

Maintenance, Service, and Repair
Motor
Page 4
MOTOR SERVICE LIMITS AND SPECIFICATIONS
Motor Specification
Number
Undercut Depth
Commutator Diameter
(min)
Brush Length
(min)
Wire Depth
(max)
mm inches mm inches mm inches mm inches
L94-4006 0.635 0.025 96.8 3.810 19.05 0.75 - -
A02-4011 1.0 .04 69.9 2.75 16 0.62 - -
ER5-4001
XP-2023
1.0 .04 69.9 2.75 16 0.62 - -
ER5-4002 1.0 .04 69.9 2.75 16 0.62 - -
BP5-4002 1.0 .04 69.9 2.75 16 0.62 - -
