Taylor-Dunn MX-026-00 - Charger, Lestronic and Signet

Illustrated Parts
Parts
Page 18
Charger, Lestronic and Signet
Built In Charger, Signet Model HBS
No internally serviceable components
6
8
5
4
3
7
11
1
2
8
3
4
5
10
7
6
2
1
8
9
Typical Lester Built In charger
Typical Lester Portable charger
Signet Chargers
Model and Type Part Number
24 volt HB, Flooded Battery 79-302-20
24 volt HBS Flooded Battery *
24 volt HB Gel Battery *
24 volt HBS Gel Battery *
* - Not available at time of printing
NOTE: There are no user serviceable components inside
the charger
NOTE: The charger AC cord is an intergral part of the
charger. When replacing the charger, do not cut and
splice the AC cord. Cutting the AC cord will void
the charger warranty.
NOTE: The Signet model HBS series charger replaces all
previous Signet models.
NOTE: The harness connectors and AC plug are not
included with the charger.
QTY PART # DESCRIPTION
2 75-318-20 Butt splice
2 75-320-51 Knife connector
1 76-200-00 AC plug, 115v domestic
