Maintenance, Service, and Repair
Transaxle - SS-534
Page 10
HARDWARE TORQUE
If hardware is not listed here, refer to standard torque
values in the appendix.
Description Foot Pounds Newton Meters
Motor Terminals 7.5-9.1 10.2-12.4
Ring Gear Bolts 65-80 93-114
Carrier Bearing Cap Bolts 70-85 100-121
Spanner Nut Lock Bolts 12-25 18-35
Pinion Nut 175 250
