Maintenance, Service, and Repair
Transaxle - SS-536, SS-546, MX-600
Page 9
HARDWARE TORQUE
If hardware is not listed here, refer to standard torque
values in the appendix.
Description Foot Pounds Newton Meters
Motor terminals 7.5-9.1 10.2-12.4
Motor Mounting Bolts 6-8 8-10.5
Final Drive Gear Nuts 35-45 48-61
Differential Bearing Cap Bolts 35-45 45-61
