Taylor-Dunn MX-026-00 - Electrical, Miscellaneous; Frame and Body, Deckboards; Frame and Body, Seat Cushions

Illustrated Parts
Parts
Page 24
Frame and Body, Seat Cushions
Item No. Part No. Description Qty
90-408-10 Deck, SS-536, SS-546
90-409-00 Deck, SS-534
94-025-51 Deck Trim, SS-534
50-112-00 Deck Prop Rod, SS-534 1
88-587-90 Retainer, Prop Rod 1
91-809-00 Mount, Prop Rod 1
90-408-20 Deck, MX-600
97-840-00 Vice, MX-600
00-300-01 Vise Mount Plate 1
88-100-15 3/8"NC X 1-3/4" Hex Head Bolt 3
88-108-62 3/8" Lockwasher 3
00-300-08 Deck Cover, Steel, MX-600 (optional)
Frame and Body, Deckboards
Item No. Part No. Description Qty
93-004-00 Seat back, SS-536, SS-546 1
90-144-00 Seat Back, SS-534 (optional) 1
90-144-00 Seat Back, MX-600 1
93-005-00 Seat Cushion, SS-536, SS-546 1
90-166-00 Seat Cushion, SS-534 1
96-006-00 Seat Cushion, MX-600 1
90-109-50 **Seat Frame, Back, Fold down SS-534 (optional) 1
90-109-50 **Seat Frame, Mount, Fold down SS-534 (optional) 1
90-090-00 Rear Step, SS-534
02-536-11 Seat Frame, fold down, SS-536, SS-546 1
02-534-25 Hip Restraints, SS-534 2
** - Fold down seat frame requires installation of the rear step.
Item No. Part No. Description Qty
62-033-48 Throtle Module 1
72-005-00 Heallight assembly 1
72-072-00 Bulb, headlight
71-102-10 Interlock switch, Seat 1
02-610-18 Mount, Interlock switch 1
96-773-00 Spring, Interloc switch 2
85-030-00 Clevis pin, interlock switch 2
88-527-11 Cotter pin 2
Electrical, Miscellaneous
