Chapter -
Wire Diagrams
The vehicle wiring diagrama are too large to be legible when printed at this size.
A full size diagram (22 x 16) is included on the CD in PDF format. You can
access the diagram from a button on the CD menu.
The diagram file names are:
SCH-00031: Models SS-534, SS-536, SS-546
SCH-00032: Moldes MX-600
12
Charger AC Cords:
If you are not familiar with standard AC power wiring,
then refer repair to a qualified licenced electrician.
Depending on the charging system, two different color
codes are used for the AC power source.
United States Standard 120 Volt:
White - Neutral
Black - Hot
Green -Ground
European Standard:
Blue - Neutral
Brown - Hot
Green/Yellow - Ground
Charger AC power source is High Voltage. Only
personnel qualified for work high voltage AC power
lines should repair the charger AC power cord.
Improper repair or incorrect wiring may result in
an electrical shock hazard causing severe bodily
injury or electrocution.
