Illustrated Parts
Parts
Page 6
Axle Assembly, 3rd Member, SS-534
Axle Assembly, Belt Drive, SS-534
Item No. Part No. Description Qty
- 30-114-00 Motor pulley, 2.25” dia -
- 30-115-00 Motor pulley, 2.75” dia -
- 30-116-00 Drive pulley, 8” dia -
- 30-117-00 Drive pulley, 11” dia -
-- 30-601-00 Drive belt (8” pulley) 2
- 30-613-00 Drive belt (11” pulley) 2
