Illustrated parts
Parts
Page 27
* Not available at time of printing
Headlights
Item No. Part No. Description Qty
1 72-005-00 Heallight 1
2 71-039-11 Switch, SS 5-34, SS 5-36, SS 5-46 1
71-100-00 Switch, MX 6-00 1
3 71-505-05 Mount, geared steering option 1
4 75-166-35 Harness, MX 6-00 1
5 88-100-09 3/8NC x 3/4 Hex bolt 1
6 88-109-87 3/8NC KEPS nut 1
Taillights
Item No. Part No. Description Qty
1 72-022-00 4" Round Stop & Tail Light Assy 2
72-025-00 Oval Stop & Tail Light Assy Complete 2
2 72-022-51 Round Rubber Grommet 2
72-025-51 Oval Raubber Grommet 2
3 72-022-52 Pig Tail (For Both Stop & Tail Lights) 2
4 72-023-20 Strobe Light, 12-48 Vdc, Amber 1
5 72-023-32 Pole for Strobe Light (MX-600 Only) 1
6 88-025-06 8-32 X 1/2" Truss Head Machine Screw 3
7 88-028-62 #8 Lockwasher 3
8 88-029-80 8-32 Hex Nut 3
Not 75-106-13 Wire Harness (For Strobe Light) 1
Shown 98-603-00 3/8" ID Rubber Grommet (For Harness) 1
72-023-21 Flash Tube for Strobe Light 1
NOTE: 72-022-00 4-inch Round Light is installed on the SS5-34 and the 72-025-00 Oval Light is installed on the
SS5-36 and MX-600.
NOTE: All strobe light information is for the MX-600 at the time of printing no strobe light information was
available. However the part number 72-023-21 is the flash tube for all strobe lights.
