SAFETY RULES AND OPERATING INSTRUCTIONS
Safety Rules
Page 2
STANDARD SPECIFICATIONS
ITEM MODEL VOLTAGE SPECIFICATION
Occupancy Driver and one passenger
Dimensions B 1-50 274.2L X 112.5W X 120.7H Centimeters
107.95L X 44.29 X 47.5H Inches
MX 1600 274.2L X 112.5W X 207.6H Centimeters
107.95L X 44.29 X 81.75H Inches
Turning Radius 279.4 Centimeters (110 inches)
Dry Weight B 1-50 376.5 kg (830 lbs)
Without Batteries MX 1600 469.9 kg (1036 lbs)
Min/Max Battery 166 kg to 212 kg (366 lbs to 468 lbs)
Weights
Maximum Load B 1-50 726 kg (1600 lbs)
MX 1600 454 kg (1000 lbs)
Electrical System 36 Volt 6-217 Amp Hour, 6 Volt, Lead Acid Batteries,
Solid State Speed Control, 275 Amp
Transmission Helical Gear, Oil Bath, Direct Drive
Motor, DC Series Wound 36 volt 6 hp @1200 RPM for 5 minutes
2 hp @ 2800 RPM for 60 min
Maximum Recommended 19.3 kph (12 mph)
Speed
Brakes Rear Wheel Mechanical Drum, Foot Operated Park Brake
Steering Automotive Steering 24:1
Tires 5.70 X 8 Load Range B, Tire Pressure 60 psi max
Frame B 1-50 Steel Unitized Body, Heavy Duty 16 Gauge Steel,
Diamond Plate
MX 1600 Steel Unitized Body, Heavy Duty 16 Gauge Steel,
Tool Box, Ladder Rack, Vise, Work Bench,
Gas Weld Tank Compartment
Instrumentation Battery Status Indicator, Key Switch, Horn Button,
Forward/Reverse Switch, Brake Light
Light Accessories B 1-50 12 Volt Brake Light
MX 1600 12 Volt Headlight, Tail/Brake Light
Charger 36 Volt 110 Volt 12 Amp AC, 25 Amp DC, Built-In, Automatic with
Control system Interlock Relay
