Taylor-Dunn MX 1600 - Important Notes and Instructions

TABLE OF CONTENTS
Charger Models:
HBS 600
HBS 1000
Signet
®
Charger
Troubleshooting
Definitions: ............................................2
Test Equipment Required for
Troubleshooting ...............................2
Important Notes and Instructions 2
Operating Instructions and Theory of
Operation ........................................3
Testing the Charging Cycle ....................4
Status Light Error Code Table................5
Troubleshooting.....................................6
Rev C
Turn the Key switch OFF BEFORE
disconnecting the batteries. Disconnecting
the batteries with the key switch ON may
corrupt the controller programming
resulting in a fault code 1 (refer to fault
table).
GEL batteries must be charged with a charger configured for
GEL batteries. Use of any other charger will result in damage
to the batteries and premature failure of the batteries.
