HARDWARE IDENTIFICATION
Standard Head Markings
S.A.E. Grade 2 S.A.E. Grade 5
Truss Head, grade 2 Carriage Bolt, grade 2
(unless marked as above)
Other Bolts
NOTE: Torque value used should be for lowest grade of hardware used. If a grade 2 nut is used on a
grade 8 bolt, use grade 2 torque value.
NOTE: Toque values specified are for clean dry threads.
Hex Bolts
S.A.E. Grade 8
L’9
L’9
