TABLE OF CONTENTS
®
Operating Instructions and Theory of
Operation ........................................2
HB/PT and GEL Indicator Lamps...........3
Testing the Charging Cycle ....................3
Test Equipment Required for
Troubleshooting ...............................4
Important Notes and Instructions 4
Status LED Error Code Table ................5
Troubleshooting.....................................6
Turn the Key switch OFF BEFORE
disconnecting the batteries. Disconnecting
the batteries with the key switch ON may
corrupt the controller programming
resulting in a fault code 1 (refer to fault
table).
