Illustrated Parts
PARTS PAGE 3
Front Axle/Steering Knuckle
ITEM # PART # DESCRIPTION QTY
15-200-40 Complete Front Axle Assembly. Includes Hubs, Tire Rod and Spring (no brakes)
00-240-21 Complete Front Axle Assembly. Includes Hubs, Tire Rod and Spring (Disc brakes)
1
14-240-06 Left Steer Knuckle, no brake 1
14-240-04 Left Steer Knuckle, disc brake 1
2 21-009-10 King Pin 2
3
01-240-74 Axle Beam . Includes #19 and #20 (no brakes) 1
01-240-75 Axle Beam . Includes #19 and #20 (disc brakes) 1
4
14-240-05 Right Steer Knuckle, no brake 1
14-240-03 Right Steer Knuckle, disc brake 1
5 - - -
6 - - -
7 87-074-00 Grease Fitting 2
8 80-309-10 Thrust Bearing 2
9 45-338-00 Grease seal 2
10 80-103-00 Race 4
11
12-124-00 Hub (includes #9, #10 and 1 of #12) 2
12-158-10 Hubwith disc rotor (includes #9, #10 and 1 of #12) 2
12 80-017-00 Bearing 4
13 88-239-85 3/4-NF Castle Nut 2
14 92-104-00 Bearing cover 2
15 88-527-14 1/8 x 1-1/2 Cotter Pin 2
16 88-289-81 7/8-NF Thin Pattern Hex Locknut 2
17 88-228-61 3/4-SAE Flat Washer 2
18 97-236-00 Wheel Nut 10
19 32-204-00 King Pin Bushing 2
20 32-200-00 King Pin Bushing 2
