Taylor-Dunn MX 1600 - Page 193

Illustrated Parts
PARTS PAGE 9
Steering Gear
ITEM # PART # DESCRIPTION QTY
18-308-21 Steeering Gear Assembly 1
1 18-308-70 Locking Ring 1
2 18-308-71 Adjuster 1
3 18-308-72 Worm Shaft/Ball Nut Assembly 1
4 18-308-23 Upper Worm Shaft Bearing 1
5 18-308-22 Upper Worm Shaft Cup 1
6 18-308-77 Housing 1
7 18-308-78 Pinion Shaft Seal 1
8 - - -
9 - - -
10 18-308-79 Worm Shaft Seal 1
11 18-308-82 Gasket 1
12 18-308-76 Pinion Shaft 1
13 18-308-75 Gear Lash Adjuster 1
14 18-308-84 Side Cover 1
15 18-308-86 Lock Nut 1
16 18-308-83 Side Cover Screws 3
17 18-308-85 Shim Kit 1
