Illustrated Parts
PARTS PAGE 11
Front Suspension
ITEM # PART # DESCRIPTION QTY
1 87-074-00 Grease Fitting 2
2 96-248-01 Spring Eye Bolt (includes #1) 2
3 32-213-00 Spring Eye Bushing 2
4 88-169-82 9/16-NF Lock nut, Grade C 2
5 85-506-05 Leaf Spring (includes #3) 2
6 96-118-00 1/2-NC x 1.87 x 6.5L U-bolt 2
7 96-123-00 3/8-NC x 2.06 x 4L U-bolt 4
8 88-149-81 1/2-NC Lock nut 4
9 16-872-03 Shackle Strap 2
10 01-200-63 Spring Support 2
11 88-109-81 3/8-NC Locknut 8
12 16-865-06 Spring Plate 2
