Illustrated Parts
PARTS PAGE 13
Transmission (Dana Spec# 012AJ310-1)
ITEM # PART # DESCRIPTION QTY
4C-150-00 Complete Transmission Assembly Including Mechanical Brakes
4C-150-10 Complete Transmission Assembly Including Hydraulic Brakes
1 Special order Housing 1
2 80-480-10 Inner Input Shaft Bearing 1
3 31-265-00 Gear set 1
4 80-480-15 Outer Input Shaft Bearing 1
5 88-840-12 Snap Ring 3
6 Special order O-ring 3
7 Special order Bore Plug 2
8 66-610-35 Intermeadiate Shaft Bearing 2
9 80-715-00 O-ring 2
10 80-480-00 Differential Bearing 2
11 96-330-10 Bearing Cap Screw 2
12 41-127-94 Fill/Drain Plug 1
13 Special order Gear Case Cover 1
14 66-610-04 Differential 1
15 Special order Bolt, Final Gear 4
16 Special order Nut, Final Gear 4
17 66-610-68 Bolt, Cover Plate 10
