Illustrated Parts
PARTS PAGE 15
Rear Axle and Brakes
ITEM # PART # DESCRIPTION QTY
41-347-98 Complete Brake Assembly (left), includes 1, 5, 7, 9, 10, 11, 12, 16 1
41-347-99 Complete Brake Assembly (right), includes 1, 5, 7, 9, 10, 11, 12, 16 1
1 41-347-15 Brake Arm 2
2 45-303-00 Seal 2
3 32-509-10 Bearing retainer 2
4 80-505-10 Bearing/Race assembly 2
5 41-347-00 Backing Plate 2
6 45-303-10 Dust seal 2
7
41-347-25 Spider, Mechanical Brake 2
41-347-27 Spider, Hydraulic Brake 2
8a 41-171-10 Axle shaft (right), does not include #17 wheel stud 1
8b 41-170-10 Axle Shaft (Left), does not include #17 wheel stud 1
9 85-215-00 Spring 2
10a 85-411-10 Spring (green) 2
10b 85-411-15 Spring (red) 2
11 41-635-00 Brake Shoe Set (1-wheel) 2
12 41-347-31 Adjusting Screw 2
13 41-516-00 Brake Drum 2
14 66-610-79 Bolt 8
15 66-610-80 Nut 8
16 41-347-34 Hairpin Clip 4
17 66-610-28 Wheel Stud 10
18 41-347-33 Adjusting Screw Nut 2
19 41-347-30 Adjusting Screw Socket
