Taylor-Dunn MX 1600 - Page 201

Illustrated Parts
PARTS PAGE 17
Rear Suspension
ITEM # PART # DESCRIPTION QTY
1 88-140-17 Bolt 4
2 85-506-10 Leaf Spring (includes #7) 2
3 96-118-00 U-bolt 2
4 88-149-81 Nut 8
5 96-248-01 Spring Bolt 2
6 01-200-62 Spring Support 2
7 32-213-00 Spring Eye Bushing 2
8 88-169-82 Nut 2
