Taylor-Dunn MX 1600 - Page 205

Illustrated Parts
PARTS PAGE 21
Brake and Accelerator Pedal and Linkage
ITEM # PART # DESCRIPTION QTY
1 98-200-00 Brake Pedal Pad 1
2 01-432-98 Brake Pedal 1
3 88-089-81 Nut 1
4 88-080-11 Bolt 1
5 00-200-45 Brake Pedal Arm 1
6 80-410-20 Bushing 4
7 88-109-81 Nut 8
8 88-100-09 Bolt 8
9 01-200-49 Brake Cable Mounting Bracket 2
10 88-517-11 Cotter Pin 8
11 96-818-10 Brake Cable 1
12 85-250-00 Spring 1
13 00-200-49 Brake Cross Shaft 1
14 00-200-48 Park Brake Linkage 1
15 88-065-09 1/4-NC x 3/4 Truss Head Machine Screw 3
16 - - -
17 50-002-01 Brake Rod 1
18 88-099-80 Nut 2
19 96-773-00 5/16 x 1 Clevis Pin 7
20 01-200-47 Brake Equalizer 1
21 96-826-09 Cable Lock 4
22 96-826-12 Brake Cable 2
23 88-847-06 E-clip 2
24 96-754-00 Brake Cable Clevis 4
25 51-344-80 Park Brake Handle 1
26 88-080-11 Bolt 2
27 88-089-81 Nut 2
28 88-088-61 Flat Washer 2
29 96-763-00 Clevis 3
31 88-069-81 1/4-NC Nylon Locknut 3
32 98-254-25 Accelerator Pedal Mounting Bracket 1
33 98-254-00 Accelerator Pedal 1
