Taylor-Dunn MX 1600 - Page 207

Illustrated Parts
PARTS PAGE 23
Wheels and Tires
ITEM # PART # DESCRIPTION QTY
1
Tubeless Wheels
12-012-00 5 x 8" Tubeless (standard) 4
12-020-00 8.5 x 8 Tubeless 4
2
Tires
10-081-00 5.70 x 8 (standard) 4
10-082-00 5.70 x 8 Extra Grip 4
10-083-00 5.70 x 8 LR C 4
10-093-00 8.50 x 8 LR B 4
10-091-10 8.50 x 8 Knobby 4
10-092-00 8.50 x 8 LR C 4
10-086-00 5.00 x 8 Man-Toterswith lugs (soft solid) 4
Split Rim Wheels
3 12-041-12 Inner Wheel (2.5 bead) 4
4 12-041-13 Outer Wheel (2.5 bead) 4
5 12-041-00 Wheel Assembly, 2.5 bead width (includes #3, #4, #6, #7, #8) 4
3a 12-042-12 Inner Wheel (12-bolt) 4
4a 12-042-13 Outer Wheel (12-bolt) 4
5a 12-042-00 Wheel Assembly, 3.75 bead width (includes #3a, #4a, #6, #7, #8 4
6 88-110-09 3/8 x 3/4-NF Hex Bolt, grade 5 4
7 88-109-62 3/8 Split Lock Washer 4
8 88-119-80 3/8-NF Hex Nut 4
9 97-236-00 Wheel Nut 20
Not Shown 13-989-00 Valve stem, tubless tire only
Not Shown 11-041-00 8.50 x 8 Tube
Not Shown 11-040-00 5.70 x 8 Tube
Tire and Wheel Assemblies
13-742-00 5.70 x 8 (standard) 4
13-742-40 5.70 x 8 Man-Toter
13-742-11 5.70 x 8 Split Rim
13-746-10 8.50 x 8
