Illustrated Parts
PARTS PAGE 27
Speed Control Panel
ITEM # PART # DESCRIPTION QTY
62-019-00 Complete Control Panel Assembly 1
1 88-838-06 #14 x 1/2 Pan Head Screw Type D Thread 10
2 62-204-00 PMC Speed control 1
3 72-501-39 Solenoid (forward or reverse) 2
4 61-838-41 Bus Bar 2
5 88-088-62 5/16 Split Lock washer 10
6 88-099-91 5/16-NF Thin Pattern Nut 10
7 88-048-62 #10 Split Lock Washer 3
8 88-049-80 10-32 Hex Nut 3
9 61-838-42 Bus Bar 2
10 72-501-38 ISO Solenoid 1
11 79-840-00 Small Circuit Breaker 2
12 79-844-00 Large Circuit Breaker 1
13 88-080-11 5-16-NC x 1 Hex Bolt 4
14 01-534-80 Mounting Panel 1
15 73-004-20 Horn 1
16 88-088-62 5/16 Split Lock Washer 4
17 88-089-80 5/16-NC Hex Nut 4
18 88-818-06 #8 x 1/2 Pan Head Screw Type B Thread 4
19 88-817-09 #8 x 3/4 Phillips Head Sheet Metal Screw 2
20 78-302-50 250 ohm 5W resistor 1
Not Shown 88-060-09 1/4-NC x 3/4 Pamel Mounting Bolt 3
Not Shown 88-069-81 1/4-NC Nylon Locknut (panel mounting) 3
Not Shown 75-148-25 Control Panel Harness 1
