Taylor-Dunn MX 1600 - Page 213

Illustrated Parts
PARTS PAGE 29
Miscellaneous Electrical
ITEM # PART # DESCRIPTION QTY
Not Shown 75-148-79 Chassie Control Harness 1
Not Shown 75-149-79 Power Harness, B 1-50 1
Not Shown 75-149-82 Power Harness, MX 1600 1
Not Shown 98-599-15 Plastic grommet for 1.75 hole
Not Shown 98-599-20 Plastic Grommet for 2.5 hole
Not Shown 75-114-20 Windsheild Wiper Harness 1
Not Shown 75-148-81 Headligh Harness 1
Not Shown 75-148-80 Harness for Pole Mounted Strobe Light 1
Not Shown 75-107-10 Potratble Charger Harness 1
Not Shown 76-013-00 Portable Charger Receptacle 1
1 73-005-05 Reverse Warning alarm 1
2 96-650-01 Wire Harness Clip, stick on
3 96-642-00 Wire ahrness Clip, push mount
4 62-033-00 Accelerator Module 1
5 71-122-20 Horn Switch 1
6 88-065-06 1/4-NC x 21/2 Phillips Truss Head Screw, Horn Switch 2
7 88-069-81 1/4-NC Hex Nylon Locknut, Horn Switch 2
8 71-111-00 Brake Light Switch 1
9 88-045-06 10-32 x 1/2 Machine Screw, brake light switch 2
10 71-102-10 Seat interlock Switch 1
11 85-030-00 Spring 2
12 96-773-00 Clevis Pin 2
13 02-610-18 Mounting Plate 1
14 88-527-11 Cotter Pin 2
15 96-640-00 Clamp, 3/16 Push Mount
16
96-629-80 (not shown) Clamp, Rubber Lined 3/16 ID
96-630-00 (not shown Clamp, Rubber Lined 5/8 ID
96-630-50 (not shown Clamp, Rubber Lined 5/8 ID (.265 mounting hole)
96-631-00 (not shown Clamp, Rubber Lined 3/4 ID
96-631-10 (shown) Clamp, Rubber Lined 1.0 ID
96-631-15 (not shown Clamp, Rubber Lined 1-1/2 ID
17
96-624-00 Clamp, 1/4 Jiffy Clip
96-625-00 (not shown) Clamp, 5/16 Jiffy Clip
18 96-626-00 Clamp, 7/8 Jiffy Clip
