Illustrated Parts
PARTS PAGE 31
Charger Lester Model# 22740
ITEM # PART # DESCRIPTION QTY
79-303-15 Complete Charger Assembly
1 79-805-67 Timer Assembly 1
1a 79-808-00 Timer Relay (not shown)
2 79-902-00 Capacitor 1
3 79-749-13 Diode Assembly 1
4 79-644-31 Transformer 1
5 * AC cord
6 * Strain Releif
7 79-831-00 Fuse 1
8 79-530-00 Strain Releif 1
9 -
10 -
11 79-809-60 Interlock Relay 1
*- See Seat Cushions, Deck and Lights
Charger Lester Model# 11860-225(export)
ITEM # PART # DESCRIPTION QTY
79-304-65 Complete Charger Assembly
1 79-805-82 Timer Assembly 1
1a Special Order Timer Relay (not shown) 1
2 79-902-00 Capacitor 1
3 79-745-10 Diode Assembly 1
4 Special order Transformer 1
5 * AC cord
6 * Strain Releif
7 79-831-00 Fuse 1
8 79-530-00 Strain Releif 1
9 -
10 -
11 79-306-23 Interlock Relay 1
