Illustrated Parts
PARTS PAGE 35
Batteries
ITEM # PART # DESCRIPTION QTY
1 50-243-10 Battery Hold Down Rod 3
2 50-250-00 Bat-Lok 3
3 88-088-66 Flat Washer 3
4 88-069-81 Nut 3
5 75-235-08 Battery Jumper 5
6 88-081-12 Bolt 12
7 88-089-80 Nut 12
8 - -
9 77-042-00 T 105, 217AH Battery (standard) 6
77-042-50 TD217, 217AH Battery
77-042-80* 217AH Moist Charge
77-044-00 T 125, 230AH Battery
77-047-00 T 145, 244AH Battery
77-047-50 TD 250, 250AH Battery
77-047-80* 244AH Moist Charge
77-048-00 J250, 250AH Battery
77-048-80 J250, 250AH Moist Charge
Not Shown 77-055-01 Low Level Electrolyte Alarm
*- Moist charge batteries must be filled with battery electrolyte before being put into service.
