Illustrated Parts
PARTS PAGE 37
Seat Cushions, Deck and Lights, B 1-50
ITEM # PART # DESCRIPTION QTY
1 72-005-00 Head Light Assembly 1
1a 72-072-00 Replacement Bulb only 1
Not Shown 98-603-00 Wiring Grommet 1
2 94-201-00 T/D Emblem 1
2a 88-567-91 Emblem Mounting Clips 3
3 94-035-01 Cowl Moulding 8'
4 90-147-00 Seat Cushion 2
5 90-179-00 Seat Backrest 1
Not Shown 88-837-09 Backrest Mounting Screws 6
6 90-444-50 Deck Board (standard) 1
6 * Deck Board (Cab) 1
7 94-035-01 Seat Back Moulding 7
8 79-575-30 Charger AC Cord 1
8a 79-511-00 Mounting Bracket 1
8b 88-065-06 Mounting Bracket Screws 2
8c 88-069-81 Mounting Brackt Nuts 2
8e 79-530-00 AC Cord Strain Releif 1
8f 76-200-00 Replacement AC Plug only 1
Not Shown 72-022-00 Tai light (includes mounting grommet and pigtail) 1
Not Shown 72-022-51 Tail light mounting grommet 1
Not Shown 72-022-52 Tail light pigtail 1
*- For fiberglass cab option, order standard deck board (#6) and cut to 60-3/8 inches long.
